Turning speed n 0~2r/mi 25T Truck Mounted Crane Elevation of boom -2~80° hydraulic boom
I. Working Condition
1,Allowed working condition: solid, stable land, the vehicle should be horizontal
2,Wind force: ≤6 degree
II. Main Parameters
Items | Unit | Value | |
Working Performance Parameters |
Max. Rated lifting weight | kg | 25000 |
Max. Lifting force of the basic boom | kn.m | 970 | |
Max. Lifting force of the longest main boom | kn.m | 470 | |
Max. Height of the main boom | m | 40 | |
Max. Height of the vice boom | m | 48.2 | |
Max. Speed of the single rope (the second stage) | m/min | 120 | |
Working Speed | Extension time of the lift boom | s | 110 |
Lifting time of the lift boom | s | 60 | |
Turning speed | r/min | 0~2 | |
Traveling Parameters | Max. Traveling speed | km/h | 70 |
Max. Grade ability | % | 30 | |
Min. Turning radius | m | 11 | |
Min. Ground clearance | m | 0.27 | |
Approaching angle | ° | 16 | |
Departure angle | ° | 11 |
III. Standard Equipments
1. Electric system
2. Hydraulic system
3. Outrigger
4. Superstructure control system
5. Chassis control system
6. Tool box
