50kw Electric Generator Lighting Fire Department Vehicles With Power Distribution System

50kw Electric Generator Lighting Fire Department Vehicles With Power Distribution System

  • High Light

    light up fire truck

    ,

    water fire truck

  • Dimension
    6705×2200×3210 Mm
  • Gross Weight
    8150kg
  • Generator Model
    STC-50
  • MaxSpeed(km/h)
    95
  • Rated Power
    139kw
  • Max. Speed
    95km/h
  • Main Lamp
    2x8kw
  • Product Name
    Lighting Fire Department Vehicles
  • Place of Origin
    SHANGHAI,CHINA
  • Brand Name
    ISUZU
  • Certification
    ISO9001/CCC
  • Model Number
    JDX5080TXFZM50
  • Minimum Order Quantity
    1 UNIT
  • Price
    Negotiable
  • Packaging Details
    Nude packing
  • Delivery Time
    90 days after sign contract
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    300 units/year

50kw Electric Generator Lighting Fire Department Vehicles With Power Distribution System

50kw Electric Generator Lighting Fire Department Vehicles With Power Distribution System



Vehicle

Dimension (L×W×H) 6705×2200×3210mm
Gross weight 8150kg
Complete vehicle shipping mass 3925kg
Electric generator rated power 50kw
Seat (inc. driver) 3
Rated power 139kw



Main lighting system



50kw electric generator, 2x8kw main lamp, pneumatic lifting poker, holder, controller, air compressor, power distribution system, auxiliary lighting.



Electric generator model ZD50TFY/4
Rated power 50 kw
Rated current 72.2A
Rated speed 1500 r/min
Poles 4
Rated line voltage 400VAC
Rated phase voltage 230VAC
Frequency 50Hz



FAQ

1, Q: Why should we choose you ?
A: We are professional manufacture located in Shanghai city for firefighting trucks
products which nearby Pudong International Airport, is easily for customer coming
and visiting.
B: We can export directly to overseas customer, no need to deal with trading company
and the second price increase will not occur
C: We have our own R&D team, production workshop, QC management team,
international marketing team and after service team.
D: We will provide the most professional and the best service on every business
discussion and operation procedure.
E: We can provide special design for different specification requirement according to
different orders or tender documents.
G: We have jointed ventures with Morita for 4 years, so the technology, design and
quality are same with Morita.
H: We have collaboration with various top enterprises of fire protection sector, Such as
Darley, Rosenbauer, HALE, AKRON, Ekhart, etc.
I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC.
2, Q: What's your Payment method?
A: T/T 30% deposit, balance will be paid by T/T before delivery
B: 100% L/C before start production
3, Q: What logistics ways we can work for shipment?
A:We can ship fire trucks by various transportation tools
B:We will go by sea to all main continents such as South America, Middle East, Africa,
Oceania and Europe etc.
C:Also we can ship trucks by road or railway to the neighborhood countries of China such
as Russia, Mongolia, Kazakhstan, Uzbekistan etc.
