32m Height Max Loading 23700Kg Water Tower Fire Truck with 4800kg Water Tanker

32m Height Max Loading 23700Kg Water Tower Fire Truck with 4800kg Water Tanker

  • High Light

    heavy duty fire truck

    ,

    huge fire truck

  • Chassis Brand
    Mercedes-Benz
  • Dimension
    10330×2500×3980(mm)
  • Gross Weight
    31000(kg)
  • Working Height
    32m
  • Wheel Base
    4500 + 1350(mm)
  • Fording Depth
    500mm
  • Max Loading
    23700Kg
  • Driving
    6x4
  • Product Name
    32m Water Tower Fire Truck
  • Place of Origin
    Shanghai,china
  • Brand Name
    Jindun
  • Certification
    ISO9001,CCC
  • Model Number
    JDX5310JXFJP32
  • Minimum Order Quantity
    1 unit
  • Price
    Negotiable
  • Packaging Details
    Exporting standard package or customized packing
  • Delivery Time
    90 days after sign contract
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    300units/year

32m Height Max Loading 23700Kg Water Tower Fire Truck with 4800kg Water Tanker

32m Height Max Loading 23700Kg Water Tower Fire Truck with 4800kg Water Tanker


JDX5310JXFJP32 fire truck is a combination of water, foam, high jet three functions in a new class of high-lift truck. It is a domestic advanced level of multi-purpose fire fighting vehicles. The car is used electro-hydraulic proportional and off centrally control technology with fully hydraulic drive, three telescopic + folding side arranged a fire truck.

The whole vehicle

Full authorized total mass31000 kg
Vehicles curb weight23800 kg
Persons QTY2 + 4,including the driver
Maximum power320/435 Kw/hp


Chassis

ManufacturerMercedes-Benz
ModelMercedes Actros3344
Drive Type6 × 4
Cabmodified Crew (1 + 1 + 4),Rear rack installation four SCBA
Wheelbase4500 + 1350 mm
Chassis weight9230Kg
Maximum allowable load23700Kg
Maximum speed104Km / h
EngineV-type 6-cylinder turbocharged and intercooled diesel engine
ModelMercedes-Benz OM501 LA
Maximum engine power320Kw / 1800r / min
Maximum torque2100N.M / 1080rpm
Emission standardEuro IV
Clutchmonolithic, dry type
TransmissionMercedes-Benz G240-16, fully synchronized gearbox.


Fire systems
 Fire performance parameters
Water / foam range: ≥65 / 60m
Foam mixer ratio: 6% (manual adjustment)
solution tank
Manufacturing: Shanghai Jindun Special Vehicle Equipment Co., Ltd.
Capacity: Water: 4800Kg Foam: 1900Kg
Material: 304 stainless steel tank, stainless steel top plate 304 patterns;
Structure: damping rubber flexible support, which consists of longitudinal and transverse anti-swing plate is mounted on the sub-frame;
Equipment: 2 individual openings with quick-locking and opening device;
2 level indicator;
2 outfalls, with stainless steel or brass ball valves;
Within a water inlet;
Four external water inlets;
32m Height Max Loading 23700Kg Water Tower Fire Truck with 4800kg Water Tanker 0


FAQ

1. Q: Why should we choose you ?

    A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

        b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

        c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.



2. Q:What's the delivery time?

    A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

        b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

        c. European brand chassis 9 months upon receipt of advance deposit.



3. Q:What's your payment method?

    A: T/T and L/C are preferred.



4.Q:Do you arrange shipment for the vehicles?

   A:Yes, we can arrange shippment based on trade terms.



5. Q: How is the packing?

    A:All the packing comply with exporting standard.



Any other questions, please do not hesitate to contact with us.
