Strobe Lights Installed Water Tanker Fire Truck With Hydraulic Control Clutch

Strobe Lights Installed Water Tanker Fire Truck With Hydraulic Control Clutch

  • High Light

    vacuum tanker fire truck

    ,

    fire pumper truck

  • Dimension
    6255×1945×2940 (mm)
  • Gross Weight
    6630(kg)
  • Seat (inc. Driver)
    2+3
  • Drive Type
    4x2
  • Wheelbase
    3360mm
  • Max. Power
    88/2900 Kw/hp
  • Tank Capacity
    Water: 2000L
  • Chassis Weight
    2070kg
  • Place of Origin
    shanghai China
  • Brand Name
    ISUZU
  • Certification
    ISO9001,CCC
  • Model Number
    JDX5070GXFSG20/F
  • Minimum Order Quantity
    1unit
  • Price
    negotiable
  • Delivery Time
    90days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram

Strobe Lights Installed Water Tanker Fire Truck With Hydraulic Control Clutch

small size Imported chassis 4X2 drive water tank fire truck 5 seats







Electrical system

The main lights in the cab at the top of the long row of lights, configure the 100W alarm control system; a strobe lights installed on both sides and the middle of each compartment.

Vehicle

Dimension (L×W×H) 6255×1945×2940 (mm)
Gross weight 6630(kg)
Complete vehicle shipping mass 4255 (kg)
Extinguishant capacity Water: 2000L
Seat (inc. driver) 2+3
Max. power 88/2900 kw/hp

Chassis

Manufacturer ISUZU
Model QL1070A1HWY
Drive type 4x2
Cab Equipped with 3 air resporator
Wheelbase 3360mm
Chassis net weight 2070kg
Max. allowable load 6725kg
Max. speed 105km/h
Min. turning diameter <13.6m
Engine type In-line six-cylinder, four-stroke, water cooling, turbocharged engine
Model 4KH1-TCG40
Max. power 88Kw/ 2900rpm/min
Max. torque 290N.M/1500rpm
Emission standard China IV
Clutch Monolithic, dry, diaphragm spring, hydraulic control
Gearbox MSB manual
