Vehicle
Dimension (L×W×H) | 6095×2000×3260mm |
Gross weight | 4000kg |
Complete vehicle shipping mass | 3925kg |
Communication command equipment total power | 1000w |
Seat (inc. driver) | 1 |
Approach angle | 20° |
Departure angle | 10° |
Front/ rear overhang | 1000/1680mm |
Lighting system
Model | CFF182400 |
Lamp power | 400x2 kw |
Lifting height | 1800mm |
Operating voltage | 220V |
Level/vertical turning angle | 360/330° |
Alarm function module
The main alarm lamp at the front of the roof is long row stroboscopic, equippedwith100w alarm system. Stroboscope lamps and clearance lamps on both side of the car body.
Painting
Red paint: body
White: roof
Post: front windshield and side body
