Vehicle
| Dimension (L×W×H) | 6705×2200×3210mm |
| Gross weight | 8150kg |
| Complete vehicle shipping mass | 3925kg |
| Electric generator rated power | 50kw |
| Seat (inc. driver) | 3 |
| Rated power | 139kw |
Chassis
| Manufacturer | Isuzu |
| Model | QL11009KARY |
| Drive type | 4x2 |
| Cab | Original X-P301 |
| Wheelbase | 3815mm |
| Max. speed | 95km/h |
| Min. turning diameter | ＜15 |
| Engine type | In-line four-cylinder, high pressure common rail, water inter-cooling |
| Model | 4HK1-TCG40 |
| Max. power | 139kw |
| Max. torque | 510N•m |
| Emission standard | China IV |
| Clutch | Diaphragm spring, monolithic, dry, hydraulic power assisted |
| Gearbox model | Manual, 6 forward gear |
Holder
| Model | TT31626 |
| Rotation angle | 360° |
| Pitching angle | 300° |
| Load | 150kg |
Wireless intelligent controller
Wireless control function:
Holder level/pitching, one key automatic reset, lifting control, operating warning light
Illumination
100m35°opening angle,illuminometer place horizontally, test point>5 LUX
FAQ
| 1, Q: Why should we choose you ? |
| A: We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting. |
| B: We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur |
| C: We have our own R&D team, production workshop, QC management team, international marketing team and after service team. |
| D: We will provide the most professional and the best service on every business discussion and operation procedure. |
| E: We can provide special design for different specification requirement according to different orders or tender documents. |
Our products are sold all over the world, you can rest assured.
