High Speed 380hp Special Vehicles 31 Ton HOWO 8x4 Dump Truck

High Speed 380hp Special Vehicles 31 Ton HOWO 8x4 Dump Truck

  • High Light

    commercial vehicle

    ,

    special operations vehicles

  • Model
    ZZ3317N386WE1
  • Drive
    8X4
  • Wheel Base
    1950+3800+1400mm
  • Engine
    MC09.38-50
  • Size (m)
    10.795x 2.55x 3.49
  • Vehicle Weight
    15.11 Ton
  • Rated Load
    15.76 Ton
  • Max. Speed
    100km/h
  • Place of Origin
    China
  • Brand Name
    Jindun
  • Certification
    IQNET,ISO
  • Model Number
    ZZ3317N386WE1
  • Minimum Order Quantity
    1
  • Price
    USD
  • Delivery Time
    3months
  • Payment Terms
    T/T
  • Supply Ability
    300/year

High Speed 380hp Special Vehicles 31 Ton HOWO 8x4 Dump Truck

31 ton HOWO 8x4 dump truck heavy truck 100km/h max speed 380hp max horsepower 12 tires





Basic information

Model ZZ3317N386WE1
Drive 8X4
Wheel base 1950+3800+1400mm
Engine Sinotruk MC09.38-50
Gear box Sinotruk HW19712L
Rear axle ratio 4.8
Size (m) 10.795x 2.55x 3.49
Tread Front track: 2022/2022mm; rear track: 1860/1860mm
Overall vehicle weight 15.11 ton
Rated load 15.76 ton
Total mass 31 ton
Tonnage level Heavy Truck
Approach angle 16
Departure angle 22



Engine

Model Sinotruk MC09.38-50
Number of cylinders 5
Fuel type Diesel
Displacement 8.8L
Emissions Euro 5
Max. speed 100km/h
Maximum horsepower 380hp
Maximum output power 276kW
Torque 1800N·m
Maximum torque speed 1100-1400rpm
Rated speed 1900rpm



Container parameters

Size (LWH) m 7.6x2.35x1.5
Container form Dump



Gear box

Model HW19712L
Forward gear 12
Reverse gear 2
Tire specification 11.00R20
Number of tires 12
Priming time ≤80s
Fuel Tank capacity 300L



Chassis

Front axle description HF7
Front axle allowable load 6500/7000kg
Rear axle description HC16 double rear axle
Rear axle allowable load 17500 (two axis group) kg
Rear axle ratio 4.8
Number of springs 11/11/12
