External Dimension 7555×2200×2560 Foton Chassis Road Wrecker Truck For Highway City Road

External Dimension 7555×2200×2560 Foton Chassis Road Wrecker Truck For Highway City Road

  • High Light

    heavy duty wrecker

    ,

    heavy wrecker trucks

  • Dimension
    5200×2120×57mm
  • Towing Weight
    7400kg
  • Lifting Weight
    1500kg
  • Full Extending Boom
    800kg
  • Max Load Platform
    3000Kg
  • Drive
    4x2
  • Place of Origin
    CHINA
  • Brand Name
    YD
  • Certification
    ISO, CE
  • Model Number
    SQZ1503PO
  • Minimum Order Quantity
    1 SET
  • Price
    USD
  • Packaging Details
    standard package in container
  • Delivery Time
    45 working days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    5 SETS PER MONTH

External Dimension 7555×2200×2560 Foton Chassis Road Wrecker Truck For Highway City Road

External Dimension 7555×2200×2560 Foton Chassis Road Wrecker Truck For Highway City Road







A,Working Condition

1,Altitude: 0-4500m

2,Temperature: -35℃--+45℃

3,Relative humidity: 80%

4,Wind force: ≤8degree



B,Working Range

KFM5071TQZ13P Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind



C,Main Parameters

Items Unit Value
Boom Structure Rated towing weight kg 7400
Max. Lifting weight kg 1500
Max. Lifting weight of full extending boom kg 800
Effective length of boom mm 1928
Extension traveling of boom mm 1200
Elevation of boom (upper/ lower) ° 7~-10
Platform Structure Min. Elevation of full extending platform ° 11
Max. Loading of platform kg 3000
External dimension of platform (length×width×height) mm 5200×2120×57
Ground clearance of cage floor mm 1041
Max. Pulling power of winch kg 4000
Dia. Of steel cable mm 10
Length of steel cable m 25
Min. Speed of steel cable m/min 2.5





Vehicle

Parameters

External dimension mm 7555×2200×2560
Chassis model   BJ1071VCJFA-S
Drive   4×2
Axle base mm 3800
The whole weight of empty load kg 4595
Load of front axle of empty load kg 1815
Load of rear axle of empty load kg 2780
The whole weight of full load kg 7495
Load of front axle of full load kg 2850
Load of rear axle of full load kg 4645
Wheel base (front/rear axle) mm 1685/1600
Front suspension mm 1120
Rear suspension mm 2220
Approach angle º 22
Departure angle º 8
Max. Speed km/h 95
Max. Grade ability % ≥28
Min. Turning diameter m ≤16
Min. Ground clearance mm 190
Engine model - CA4DC2-12E3
Rated power kw/r/min 88/3200
Engine emission ml 3168
Max. Torque n·m/r/min 320/1900-2100
Fuel type   Diesel
Standard of emission   EN III
Tire size   7.50-16,8.25-16
Persons   3
Optional Engine Engine model   YZ4DB1-30
Rated power kw 95
Engine emission ml 4087
Engine model   CY4102-C3C
Rated power kw 88
Engine emission ml 3856
Engine model   YN38CR
Rated power kw 85
Engine emission ml 3760

D,Standard Equipments

1. FOTON BJ1071VCJFA-S

2. Main boom structure assembly

3. Vice boom assembly

4. Hanging hook assembly

5. Control structure assembly

6. Winch assembly (include winch clutch, impaction device)

7. Steel body assembly

8. Tool box assembly

9. Light stands assembly

10. Alarm device

11. Hydraulic system

12. Hydraulic system over voltage protection device

13. Electric system

14. PTO Warner

15. Combination lamps

16. Steel wire rope (including hook) (25m/pcs)

17. Standard spare tire

18. L wheel lift

19. Bind belt

20. Vulnerable parts attachment
