1,Chassis
| Chassis model | Sinotruk HOWO ZZ5207TXFN471GE5 |
| Discharge | CHINA V |
| Drive | 4x2 |
| Engine model | MC07.34-50 |
| Engine power | 340HP |
| Gross weight | 20t(front axle 7t,rear axle 13t) |
| Max. speed | ≥90Km/h |
| Cab | double row |
2,Storage compartment
Box-type compartment, back pullout, stop block with every hose bridge.
3,Hydraulic tail-board
Hydraulic tail plate is mainly used for equipment support hose handling hose bridge, the whole system is mainly composed of a hydraulic power source, the tail plate, a lifting cylinder, a turning cylinder and control system, lifting and turning tail plate is realized by the hydraulic control device with manual and wire, the specific parameters are as follows:
Dimension: 2400×1800mm
Rated load: 2000kg
Lifting height: ≥1500mm
Voltage: 24V
4,water supply attachment:
Hose bridge:In the remote water supply system operation, set the water bridge protection at the intersection for fire fighting rescue vehicles.
5,Equipment list
|
No. |
Name |
Specification |
No |
Note |
|---|---|---|---|---|
|
|
Hose bridge | 300-30T | 4 | |
|
|
Tubular water separator | DN300-2×DN150 / 4×DN80 | 1 | Aluminium alloy |
|
|
Water diversion hose | 10-150-10 | 4 | |
|
|
Hose connection wrench | General type | 4 | |
|
|
Highlight flashlight | 2 | ||
|
|
Hand held anti-explosion interphone | 1 | ||
|
|
Chassis onboard tools | Standard | 1 |
Onboard documents
1,Quality warranty card of chassis
2,Certification of chassis
3,Maintenance manual of chassis
4,Water supply system service manual
5,Delivery order
