Diesel 12CMB Euro 4 Gearbox 190HP Sewer Suction Truck

China Shanghai Jindun special vehicle Equipment Co., Ltd certification
I'm Online Chat Now

Diesel 12CMB Euro 4 Gearbox 190HP Sewer Suction Truck

small.img.alt small.img.alt

Large Image :  Diesel 12CMB Euro 4 Gearbox 190HP Sewer Suction Truck

Product Details:
Place of Origin: CHINA
Brand Name: Dongfeng
Certification: ISO
Model Number: 5253GXWD
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD
Delivery Time: 2 MONTHS
Supply Ability: 500 UNITS PER YEAR
Detailed Product Description
Capacity: 2-4cbm Material: 5mm Carbon Steel
GVW: 8000kg Fuel: Diesel
Curb Weight: 4000kg Gear Box: Manual
Color: Customer's Requirement Transmission Type: Manual
Emission Standard: Euro 3,Euro 4,Euro 2
High Light:

190HP Sewer Suction Truck


4 Gearbox Sewer Suction Truck


12CMB Sewer Suction Truck

Sewage suction tanker 12CMB Euro 4 Gearbox Sewer Suction Truck 190HP


Sewage Suction truck used to collect and transfer sewage and sludge, it is the new sanitation vehicles can avoid the secondary pollution.
Sewage suction truck is suitable for the collection and transportation of feces, mud, crude oil and other liquid substances, sewage sludge, can finish loading and unloading.
Features:self-suction and self-discharge, fast working speed, large capacity, convenient transportation, sewage suction truck adopt domestic advanced suction truck vacuum pump, great suction, long-distance suck, especially can suck sewage mud, stones, bricks and other large objects.


Product Name DONG FENG sewage suction truck
Overall Size(mm) 8500×2500×3600(mm)
Sewage suction tanker 12CBM
Gross Weight(kg) 15800
Curb Weight(kg) 7700
Approaching/Departure Angle(°) 20/13(°)
Front/Rear suspension(mm) 1430/2370
Max.speed(km/h) 98
Standard Configuration 1.Sewage suction tank volume 12m3,6mm carbon steel;
2.equipped with looking sewage window,self fow exit,cleaning device,Oil water separator, overflow valve, Hydraulic lifting sewage tank.
3.8m sewage suction pipe.
4. Vertical suction range: 9m,pumping full tank time: 10 min, discharging full tank time: 8min.
Chassis Parameters
Chassis Brand Dongfeng
Chassis Model DFL1160BX1V
Drive Type 4*2, 2 axles
Transmission 8-speed, manual
Cab One and a half cabin,3 passengers.
Tire Specification 10.00-20
Tire No. 6
Wheelbase(mm) 4700
Leaf Spring No. 9/12+10
Front Trend/Rear Trend(mm) 1880/1800
Axle Loading(kg) 5600/10200
Engine Parameters
Engine Brand Chaochai
Engine Model B190 33
Engine Type Diesel, 6 cylinder, turbocharged, inter-cooled.
Horse Power(hp) 190
Displacement/Power 5900ml/140kw
Emission Standard Euro 3
