Vehicle
|
Dimension (L×W×H) | 10500×2500×3980 (mm) |
| Gross weight | 32100 (kg) | |
| Complete vehicle shipping mass | 31950(kg) | |
| Seat (inc. driver) | 2 | |
| Engine Power | 320/435(kw/hp) | |
|
Chassis
|
Manufacturer | Mercedes Benz |
| Model | Actros3344 | |
| Driving | 6×4 | |
| Cabin | Single cab | |
| Wheel base | 4500+1350 (mm) | |
| Net weight | 9230Kg | |
| Max. loading | 23700Kg | |
| Max. running speed | 90Km/h | |
| Min. turning diameter | ＜22.3m | |
| Engine type | V type, 6 cylinder in line turbo, middle cool engine | |
| Model | Mercedes OM501 LA | |
| Max. engine power | 320Kw/ 1800r/min | |
| Maximum torque | 2100N.M/1080rpm | |
| Emission standard | Euro V | |
| Clutch | Monolithic, Dry | |
| Transmission |
Mercedes G240-16 fully synchronized |
|
|
Full power PTO
|
NMV200(N56)i=1.48(speedup), Full power | |
|
PTO of transmission
|
MB-NA121-1b(N04)i=1.03/1.24 (speed up) |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
Our products are sold all over the world, you can rest assured.
