20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle

20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle

  • High Light

    20m Water Tower Fire Truck

    ,

    6x4 Water Tower Fire Truck

    ,

    6 ton 6x4 fire engine vehicle

  • Product Name
    Water Tower Fire Truck
  • Gross Weight
    31000(kg)
  • Working Height
    20m
  • Wheel Base
    4500 + 1350(mm)
  • Driving
    6x4
  • Seat
    2+4 Seats (4 Doors)
  • Max. Power
    320KW
  • Product Name
    Fire Fighting Truck Water Pump,new Fire Truck
  • Place of Origin
    Shanghai,china
  • Brand Name
    Benz
  • Certification
    ISO9001,CCC
  • Model Number
    JDX5310JXFJP20
  • Minimum Order Quantity
    1 unit
  • Price
    Negotiable
  • Packaging Details
    Nude packing
  • Delivery Time
    90days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    300units/year

20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle

20m working height Water 6ton imported chassis 6X4 water tower fire truck 28ton Foam 4ton



Waterway operation panel

At the top of pump room trail.

Alarm lamp and stroboscope lamp

In front of the vehicle roof equipped with TBD035181 long row alarm lamp, LTE595 stroboscope lamp on both side.

Controller

Finland EPEC2024 imported with original packaging

Remote Control

Italian AUTEC wireless remote controller imported with original packaging, effective working radius 100m.



Fire fighting performance

Spray flow/pressure 4200L/min @ 1.6MPa
Spray range(water/ foam) ≥70/65m
Foam proportioner 6% (manual adjustment)

Liquid tank

Manufacturer Shanghai Jindun special vehicle equipment Co., Ltd
Capacity Water: 6000kg Foam: 4000kg
Material High quality 304 stainless steel
Structure Welded frame, shock-reducing support
Equipment

2 manholes

2 fluid level gauges

2 drain outlets with stainless steel ball valve

1 outside suction port, 1 inside filling pipe end

4 outside filling ports





Vehicle



Dimension (L×W×H) 10970×2480×3900 (mm)
Chassis brand Mercedes Benz
Seat (inc. driver) 2+4 seats (4 doors)
Max. power 320KW

Chassis





Manufacturer Germany Mercedes Benz
Model Actros3344
Driving 6×4
Cabin 1+1+4
Wheel base 4500+1350 (mm)
Curb weight 14550Kg
Full loading weight 28000Kg
Max. running speed 100Km/h
Engine type V type six-cylinder, inter-cooling, electronic unit pump diesel engine
Model OM501LA.IV/4
Engine power 320Kw/1800rpm
Maximum torque 2100N.M
Emission standard EURO IV
Clutch Monolithic, dry
Gearbox Manual-automatic

20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle 0

20m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle 120m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle 220m Water Tower Fire Truck 6 Ton Imported Chassis 6x4 Fire Engine Vehicle 3

Shanghai Jindun special vehicle Equipment Co., Ltd.​ is a high-tech special vehicle enterprise and flagship company of jindun group. It owns first class factory, internationally advanced processing equipment, gathers many top technicians and industrial experts, establishes national grade technology R&D center, and has 112 types of products, including truck crane, aerial working platform truck, road wrecker truck, road maintenance truck, dump truck, CAFS fire trucks, chenical fire truck, water tank foam trucks, emergency rescue vehicles, gas supply vehicles, lighting truck, satellite communication command vehicle, road-rail convertible vehicle, aerial ladder trucks, aerial platform truck, airport fire trucks, long distance water supply truck, water tower fire truck and other general fire trucks.
