6x4 Foam Fire Truck With 16000kg Water Foam Tender For Fire Brigades

6x4 Foam Fire Truck With 16000kg Water Foam Tender For Fire Brigades

  • High Light

    6x4 Foam Fire Truck


    Fire Brigades Foam Tender Truck


    16000kg Water Foam Fire Truck

  • Chassis Brand
    Sinotruk Howo
  • Driving
  • Water Capacity
    12000 L
  • Foam Capacity
    3500 L
  • Tank Material
    Stainless Steel Or PP
  • Pump Flow
    100 L/s @1.0Mpa
  • Monitor Flow
    80 L/s @ 0.8Mpa
  • Equipment Locker
    Roller Shutter Doors
  • Product Name
    6x4 Dirve Foam Firefighting Truck
  • Place of Origin
  • Brand Name
    CIMC Jindun
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 UNIT
  • Price
    Factory price, negotiable
  • Packaging Details
    Exporting standard package or customized packing
  • Delivery Time
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    800 units per year

6x4 Foam Fire Truck With 16000kg Water Foam Tender For Fire Brigades

6x4 Foam Firefighting Truck with 16000kg Water Foam Tender for Fire Brigades



Dimension Approx. 10350×2550×3446 (mm)
Gross Vehicle weight 34000 (kg)
Engine power 340HP
Extinguishing capacity Water:12000Liters,Foam: 3500Liters
Cabin Double cabin, 2+4 persons. the rear cabin backrests fitted with four fixtures to put Self Contained Breathing Apparatus.


Manufacturer Sinotruk Howo
Driving type 6×4
Wheelbase 4600+1350 mm
Max. speed 102 km/h
Engine type In line, six cylinders, four strokes, water-cooled, direct injection, supercharged, intercooled diesel engine
Rated power 340hp (247 kw)
Max. torque 1120N.M/1200-1600rpm
Emision standard Euro III
Steering Hydraulic steering with power assistance, RHD
Gearbox HW19710,10F&2R
Tire type 12.00—20


Fire pump

Model CB10/100-G normal pressure fire pump
Pressure 1.0 Mpa
Flow 100 L/s
suction depth 7m


Fire monitor

Model PL80
Flow 80 L/s
Pressure 0.8 Mpa
Throw range Water≥75m, foam≥70m
Rotation 0-360°
Pitch -15° to 90°



Capacity Water: 12000L, foam: 3500L,
Material 304 stainless steel or PP

6x4 Foam Fire Truck With 16000kg Water Foam Tender For Fire Brigades 0

1. Q: Why should we choose you?

    A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

        b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

        c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.


2. Q:What's the delivery time?

    A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

        b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

        c. European brand chassis 9 months upon receipt of advance deposit.


3. Q:What's your payment method?

    A: T/T and L/C are preferred.


4.Q:Do you arrange shipment for the vehicles?

   A:Yes, we can arrange shippment based on trade terms.


5. Q: How is the packing?

    A:All the packing comply with exporting standard.


Any other questions, please do not hesitate to contact with us.
