Altitude 0 - 4500m Kaifan Hydraulic Truck Crane 70km / H 11 Degree Departure Angle

Altitude 0 - 4500m Kaifan Hydraulic Truck Crane 70km / H 11 Degree Departure Angle

  • High Light

    truck mounted hydraulic crane

    ,

    truck bed mounted crane

  • Altitude
    0-4500m
  • Temperature
    -25℃--+45℃
  • Wind Force
    ≤6 Degree
  • Elevation Of Boom
    -2~80°
  • Max. Torque
    1100n.m
  • Departure Angle
    11°
  • Place of Origin
    China
  • Brand Name
    KaiFan
  • Certification
    IQNET,ISO
  • Model Number
    KFM5323JQZ25G5
  • Minimum Order Quantity
    1
  • Price
    USD
  • Delivery Time
    3months
  • Payment Terms
    T/T
  • Supply Ability
    300/year

Altitude 0 - 4500m Kaifan Hydraulic Truck Crane 70km / H 11 Degree Departure Angle

Turning speed 0~2r/min 70km/h speed KaiFan Brand 25T truck Crane Lifting weight 25000kg







Two. Working Range

“KAI FAN” Brand KFM5323JQZ25G5(QY25G5)Crane is fully hydraulic telescopic crane, the maximum rated lifting capacity is 25t. It can be applied in various conditions for lifting and installation work, such as industrial and mining establishments, building site, station, sea port, warehouse and so on.





One. Working Condition

1,Altitude: 0-4500m

2,Temperature: -25℃--+45℃

3,Allowed working condition: solid, stable land, the vehicle should be horizontal

4,Wind force: ≤6 degree





Three. Main Parameters

Items Unit Value
Working Speed Extension time of the lift boom s 110
Lifting time of the lift boom s 60
Turning speed r/min 0~2
Weight Parameters The whole weight kg 31670
Load of the front axle kg 6850
Load of the rear axle (duel axle) kg 24820
Traveling Parameters Max. Traveling speed km/h 70
Max. Grade ability % 30
Min. Turning radius m 11
Min. Ground clearance m 0.27
Approaching angle ° 16
Departure angle ° 11





Dimension Parameters

External dimension(length×width×height) mm 12790×2500×3460
Vertical span of outrigger m 5.35
Horizontal span of outrigger m 6.1
Length of main boom m 10.3~39.5
Length of vice boom m 8.3
Elevation of boom ° -2~80
Chassis Model TAZ5323J
Engine model WP10.270
Rated power/speed kW/(r/min) 199/2200
Max. Torque/rotate speed N.m/(r/min) 1100/1200-1600
