ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H

ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H

  • High Light

    truck mounted aerial work platform

    ,

    vehicle mounted platform

  • External Size
    7150×2045×3550
  • Structure Type
    4-section Telescopic Boom
  • Working Height
    22000
  • Max. Speed
    90(km/h)
  • Working Radius
    13400
  • Persons
    2
  • Place of Origin
    China
  • Brand Name
    KaiFan
  • Certification
    IQNET,ISO
  • Model Number
    KFM5075JGK –GKS-22Q
  • Minimum Order Quantity
    1
  • Price
    USD
  • Delivery Time
    3months
  • Payment Terms
    T/T
  • Supply Ability
    300/year

ISUZU Chassis 4x2 Drive 22M Telescopic Boom Truck Mounted Aerial Platforms 90km/H

200kg load 22M Telescopic Boom Aerial Working Platform 90km/h speed ISUZU chassis 4x2 drive





A,Working Condition

1,Altitude: 0-1000m

2,Temperature: -25℃--+45℃, environmental relative humidity ≤90%

3,Allowed working condition: solid, stable land, the vehicle should be horizontal

4,Wind force: ≤6 degree (wind speed ≤12.5m/s)



B,Working Range

KFM5075JGK Telescopic Boom Aerial Working Platform can be applied in various conditions for aerial working, such as urban road, suburban road, highway, airport, bridges and culverts and so on. The structure type is telescopic boom and the lifting boom is flexible, convenience and performance with the negative point, more suitable for narrow site conditions or other special operations.



C,Main Parameters

Bulletin No. KFM5075JGK
Type GKS-22Q
External dimensions(mm) 7150×2045×3550
Structure type Four-section telescopic boom
Working Cage Internal size(mm) 1000×650×1100
Rated loading(kg) 200(or 2 persons)
Max. Working height(mm) 22000
Max. Height from ground(mm) 20300
Rotation angle(º) Left 90 º, right 90 º
Max. Working radius(mm) 13400
Working radius when doing the highest height(mm) 4190





Working Boom

Lifting angle(º) -12~80
Out rate speed(mm/sec) 12360/70
Ret rate speed(mm/sec) 12360/70
Boom rack rotation angle(º) 360
Boom rack rotation speed(r/min) 1.0
Outrigger

)

Vertical span(mm)

4000
Horizontal span(mm) 4000
Traveling of vertical outrigger(mm) 550
Adjustment Single adjustable



D,Chassis Introduction

























Traveling

Performance

Parameters

Chassis model ISUZU NKR77LLPACJAY (EN III)
Persons 2
Axle base (mm) 3360
Wheel base (front/rear)(mm) 1504/1425
Driving mode 4×2
Front suspension(mm) 1015
Rear suspension(mm) 2100
Approaching angle(º) 24
Departure angle(º) 12
Max. Grade ability(%) 28
Min. Turning diameter(mm) 13600
Min. Ground clearance(mm) 190
Engine Engine model 4KH1-TC
Rated power(kw/r/min) 96/3400
Torque(N,m/r/min) 280/1700



Max. Speed(km/h)

90
Gas consumption per one hundred miles(diesel oil) (L) 12
Specification of the tire 7.50-15,7.50R15,7.00-16,7.00R16
The whole weight(kg) 7170
Max. Weight with whole loading(kg) 7300
