|Dimension (L×W×H)||8880×2500×3500 (mm)|
|Gross weight||14900 (kg)|
|Complete vehicle shipping mass||14450 (kg)|
|Rescue equipment quantity||100pcs|
|Seat (inc. driver)||2+4|
|Max. loading weight||18000kg|
|Min. turning diameter||<16.5m|
|Engine type||In-line six-cylinder, inter-cooling, direct injection|
|Emission standard||China IV|
|Rated output power||13.5kVA|
|Max. output power||14.5kVA|
|Electricity current||16.5A/per phase|
Lift lighting system
|Above ground level||≥6.6m|
|Control system working pressure||DC24V|
|Lamps working pressure||220V|
|Lamps horizontal rotating angle||380°|
|Lamps vertical rotating angle||330°|
Equipment layout principles
1, According to combat programming and combat development design equipment integration
2, According to human body engineering principle design all kinds of equipment frames.
3, According to using logic and frequency of use place equipment
4, 1-2 action can take any equipment standing on the ground or pedal
5, Fixed all equipment with rust-proof, vibration-proof, anti-drop, scratch-proof special clamp.
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
