JDX5130TXFJY98 rescue fire truck adopts ISUZU QL1160AMFRY chassis, equipped with a 4X1000W lighting system, Honda ET12000 generator, Finland HIAB 111 B-2CLX cranes and emergency lighting equipment, vehicle structure and reasonable layout, convenient operation and maintenance, applicable to large and medium city public security fire brigade, petrochemical enterprises and airport fire brigade for emergency vehicle. Its shape, structure , the performance of the maintenance system to achieve the level of similar imported vehicles and life expectancy.
1.Dimensions: length x width x height 8340×2460×3380
2.The full authorized total mass(kg): 13000kg
3.Vehicle kerb mass(kg): 12550kg
4.The number of rescue equipment(pieces): 98
5.Crew number(including driver)(person): 6
6.Maximum power(kW/hp): 177/240
Side girder Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.
