Diesel 1900rpm 10Bar 4x4 Advanced Emergency Aircraft Fire Rescue Vehicles

Diesel 1900rpm 10Bar 4x4 Advanced Emergency Aircraft Fire Rescue Vehicles

  • High Light

    4x4 Aircraft Fire Rescue Vehicles

    ,

    10Bar Fire Rescue Vehicles

    ,

    1900rpm Fire Rescue Vehicles

  • Drive
    4x4
  • Cabin
    1+2,1+1+3
  • Power
    177KW
  • Max Speed
    100Km/h
  • Brand
    Ziegler
  • Transmission Type
    Manual
  • Pump Capacity
    3000LPM At 10Bar
  • Priming System
    Full Automatic
  • Product Name
    Emergency Aircraft Fire Rescue Vehicles
  • Place of Origin
    SHANGHAI,CHINA
  • Brand Name
    Ziegler
  • Certification
    ISO9001/CCC
  • Model Number
    Advancer 4x4
  • Minimum Order Quantity
    1 UNIT
  • Price
    Negotiable
  • Packaging Details
    roll roll
  • Delivery Time
    90 days after sign contract
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    350 units/year

Diesel 1900rpm 10Bar 4x4 Advanced Emergency Aircraft Fire Rescue Vehicles

Ziegler Advancer 4x4 Advanced Aircraft Rescue and Fire Fighting Vehicle



Ziegler Advancer 4x4 Specification

- Ziegler Signature Fire Pump
- Airport RIV
- ALPAS-GRP-Conception
- Ziegler Roof Monitor
- Well-Known PLC or CAN-BUS Control
- Wide Rang of Chassis
- ICAO Standard Design
- High Quality Control



Type: Scania P410 CB 4x4 HHZ Chassis
Scania P-series short Crewcab, CP17L Single Cabin 1 driver + 2 co-driver seat ,All seats with seat belt

Axle 4x4
Max. output 1900 rpm 410 hp (301 kW)
Max. torque 1000-1300 rpm: 1975 Nm Injection system
Emission level Euro 3
Fuel Type Diesel
Gearbox type Automatic
Steering Right Handed, Power Steering
Suspensions

Front: leaf springs, parabolic,

Rear: leaf springs, trapezoid

Brake Air management system with pneumatic brake control and ABS.
Battery 2x12V, 180AH
Alternator 28V, 100 Amp
Acceleration less than 35 sec. from 0 – 80 km/h at operational weight
Top Speed 105 km/h, MD0
Permissible weights

total weight: 21.000kg (for airfield use possible),

front axle: 10.000kg,

rear axles: 1x11.000kg





The entire vehicle and components except for corrosion resistant material should receive
sufficient thickness of anti-corrosive layer before application of intermediate & finish coats. Th
entire underside of the vehicle including the inside should be protected. The finish paint should b
as follows:
Exterior of the body - Signal Red - RAL 3000
Front & Rear bumpers, mudguards - Brilliant White – RAL 9010 and wheel hubs
Provision is to be made for insignia or logo to be affixed.
1 white reflecting stripe laterally, width approx. 300 mm, similar as czech regulation
